The i7100 offers an extremely reliable, robust and high quality surveillance solution for security applications that demand the very best performance. Precision engineered to exacting standards, the range comes with a variety of options in order to offer the best fit solution for virtually any application.

Heat treated gravity die cast aluminium casings. 4 mm and up to 6 mm thick, the castings are suitable for installation in the harshest environments.
Over the top mount
Side mount
Height
208 mm without platform and CR
208 mm continuous rotation
Width (to platform face)
147 mm without platform
147 mm without platform
Width (to platform outer edge)
N/A
TBA
Depth (without plugs)
100 mm
100 mm
Weight
4 kg
4kg
Fixing Centres
101.6 mm
101.6 mm
Material
Cast Aluminium
Cast Aluminium
Paint
Two pack polyurethane
Two pack polyurethane
Voltages
12 V DC, 24 VDC
12V DC, 24V DC
Speeds (deg/sec)
DC
Pan 10, 30, 60
Tilt 10
Pan 10, 30, 60
Tilt 10
Capacity
5kg (Balanced load and slow speed)
8kg
Continuous rotation
Available
Availabe
Backlash
Less than 0.15º
Less than 0.15º
Temperature range (ºC)
-20 to 50
-20 to 50
i7100
